Heat treatment system

Due to our original know-how, we have realized the stable temperature control which is essential for Heat treatment. The Heat treatment system for the wide-gap semiconductor (GaN etc.) which is being the focus of recent attention has been in a great demand.

Ohmic Alloy System

OS-5500 Series (High-temperature type)

Suitable for Ohmic electrode alloy and anneal for wide-gap semiconductor (GaN, SiC, et.)

OS-4500 Series (Mid-temperature type)
Suitable for various alloy and anneal

OS-3500 Series (Low-temperature type)

Suitable for Ohmic electrode alloy and anneal for the compound semiconductor for general purpose (GaAs system and InP system)

Batch-processing wafer annealing system

The multipurpose batch-processing wafer annealing system specialized in the compound semiconductor.
The substrate is compatible of the temperature up to 700 degree and mountable up to 5 3-inch substrates.
In addition, it is equipped with the transfer mechanism of treatment room so that the processes from heating to cooling can be done with the room being closed.
The vacuum replacement mechanism is also provided for the use of diffusion of solid phase.

Vertical-type diffusion system

Since the closed pipe method is used for the zinc diffusion process that used to be done in the closed pipe, the safety and maneuverability has considerably improved while keeping the performance equivalent to that of the closed pipe method.
It is compatible to 2 inch or 3 inch wafer
Also, the double trap structure can connect the inboard disposal to the general disposal.
