CVD system


The thin membrane forming system mainly of the laser CVD system meets the demand from the wide range of fields.
In addition, all sorts of vacuum deposition and sputtering system are provided by using the high vacuum technology.

Laser abrasive CVD system

‚r-210
The continuous deposition of the multiphase ceramics such as Al2O3 and PZT which minimizes the collapse of relative proportion of component by irradiating the optical energy of laser has become capable.

Diamond deposition system

‚c‚b-1020
In order to optimize the plasma density and temperature control which would be the factors of diamond deposition, various measures are taken including the work cooling mechanism and the work positioning mechanism for plasma.

ALD system

AL-8000
It is an atomic layer deposition system capable of processing single wafer through the batch process by adopting switching mechanism for original material gas flow. By setting the system composition as cluster type, the high throughput enables to cope even with the process that tends to take longer time for processing.

Electron beam vacuum deposition system

HV-500
The electron beam vacuum deposition that restricts oxidizing material at the ultrahigh vacuum is available. The substrate is supplied without breaking the high vacuum through the load lock room, which facilitates its continuous use.
@
