Etching system

Whether it's wet etching or dry etching, the abundant technology and system are provided to respond to a wide variety of usage.

Fully-automated etching system

The wet etching process is automated and the single-wafer processing method is adopted. It is suitable for the recess etching for GaAs wafer and the metal membrane etching for the thin-film magnetic head. The organic cleaning is also available. (Substrate compatible to 4 inch to 6 inch)

Multipurpose etching system

By selecting option, it has expandability of handling from chemical etching to the plasma etching. It can be used for experiment equipments and jobbing production facilities. (Option specification)

Dry etching system for compound semiconductors

The chemical dry etching system for wide-gap compound semiconductors such as GaN, Siband ZnO.

Multi-electrode dry etching system

It is a dry etching system of multiple electrode type that can even cope with the enlarging area. The optimization of oscillation frequency enabled the multiple electrodes. By optimizing power, it can also function as the ashing, cleaning and texturing system.
